Ebike Garage Complete Rear Moto Brake + Footbrake Conversion Kit

Ultra Bee Rear Brake + EBG Footbrake — Single Caliper Hand & Foot Brake System

The ultimate rear brake upgrade for your Talaria. This complete conversion bundle replaces your stock rear brake, stock rotor, and stock caliper mount with a full Ultra Bee moto-grade rear brake system AND integrates the Ebike Garage Footbrake using a single caliper setup.

Using the Ebike Garage pass-through footbrake design, both your hand brake and footbrake connect directly to the footbrake master cylinder and operate a single Ultra Bee rear caliper — giving you true moto-level stopping power with full hand and foot brake control.

If you're running more power, riding aggressively, or want true moto-grade braking performance and control, this is the complete rear brake solution.

🔗 Choose Your Setup — Other Versions of This Kit

This kit comes in three different configurations. Pick the one that fits how you ride:

• Single Caliper — Hand + Foot Brake (this kit)— One Ultra Bee rear caliper actuated by both your handbrake AND footbrake. Clean setup, full braking control from either input.
• Dual Caliper — Hand + Foot Brake — Two independent Ultra Bee rear calipers: one for the handbrake, one for the footbrake. Fully separated systems for maximum redundancy and braking power.
• Footbrake Only — Single Ultra Bee rear caliper actuated by the footbrake only. Handbrake is removed entirely for a clean, dedicated foot-operated rear brake.

Not sure which version is right for you? Email us or use the chatbox — we'll help you pick the right setup for your build and riding style.

⚙️ FITMENT

This kit is built for: Talaria Sting MX3 & Talaria Sting MX4

• Talaria Sting MX3
• Talaria Sting MX4

Designed specifically for the Talaria Sting platform.

What's Included

• Ebike Garage 230mm Rear Floating Brake Rotor — oversized moto rotor.
• Ebike Garage 230mm Rear Ultra Bee Caliper Mounting Bracket (Black or Silver – select option)
• Sur-Ron Ultra Bee Full Rear Brake — OEM master cylinder, hose, and caliper
• Ebike Garage Footbrake Kit (Black or Silver – select option)
  • Pedal assembly and mounting bracket
  • Genuine Nissin master cylinder
  • Kevlar-braided brake line
  • Bronze titanium hardware kit
  • Handbrake connection valve
  • Syringe for brake bleeding
• FREE M10 Hose — connects the handbrake to the footbrake master cylinder for single-caliper hand + foot operation
• All required mounting hardware

This is the complete rear-only conversion kit — everything you need in one bundle.

How the Kit Works

This kit replaces your stock rear brake, stock rear rotor, and stock caliper mount, and replaces them with:

1. The Ebike Garage rear bracket / rotor guard
2. The 230mm Ebike Garage floating moto rotor
3. The Sur-Ron Ultra Bee rear brake (caliper, master cylinder, and hose)
4. The Ebike Garage Footbrake with pass-through master cylinder

The system uses a single Ultra Bee rear caliper. Thanks to the Ebike Garage pass-through footbrake design, the hand brake and caliper both connect straight to the footbrake master cylinder — giving you full hand + foot brake control of one powerful rear caliper.

How It Connects (Hose Routing)

You'll end up with two hoses running to the footbrake master cylinder:

1. Free M10 hose → from the footbrake master cylinder to the rear caliper. This is the new dedicated line that feeds the Ultra Bee caliper from the footbrake.
2. Stock Ultra Bee hose → from the handbrake to the footbrake master cylinder. Disconnect the included Ultra Bee hose from the rear caliper and re-route it so it runs from the handbrake into the footbrake cylinder's pass-through port.

The result: the handbrake feeds into the footbrake cylinder, and the footbrake cylinder feeds the rear caliper — so either lever (or pedal) actuates the same Ultra Bee caliper.

Why Upgrade?

The stock Talaria Sting rear brake was never designed for higher power builds or aggressive riding. This kit transforms your rear brake into a true moto-grade system with the added control of a footbrake.

Ultra Bee Rear Brake Advantages

• Significantly increased rear stopping power
• Improved braking modulation and pedal feel
• Higher heat capacity for aggressive riding
• Reduced brake fade under heavy load
• Larger piston size and stronger clamping force
• OEM Sur-Ron reliability

230mm Floating Moto Rotor

• Oversized rotor for increased braking leverage
• Improved heat dissipation
• Floating design for consistent performance under heat
• Designed for proper Ultra Bee caliper alignment

Precision CNC Caliper Bracket / Rotor Guard

• Available in Black or Silver
• Engineered specifically for 230mm Ultra Bee setup
• Integrated rotor guard for off-road protection
• Built for aggressive off-road riding

Ebike Garage Footbrake

Ebike Garage is the industry leader in high-performance footbrake systems and brake integrations for e-motos. Their precision-engineered kits deliver unmatched braking control, durability, and professional-level performance trusted by serious riders.

• CNC-machined 7075 aluminum foot brake pedal
• Genuine Nissin master cylinder
• Kevlar-braided high-pressure brake line
• Lightweight titanium hardware
• Pass-through valve allows hand + foot operation on a single caliper
• Improved control during technical off-road riding, steep descents, stunts, wheelies, and aggressive terrain
• Better throttle control with precise rear brake modulation underfoot

Performance Benefits

• Massive upgrade over stock rear brake
• True moto-level rear braking performance
• Hand brake + footbrake on a single caliper (clean, lightweight setup)
• Designed for higher power Talaria builds
• Improved downhill and technical braking control
• Better rear brake consistency under heavy load
• Professional-grade components throughout

Installation Notes

• Direct bolt-on replacement for the stock rear brake system
• A brake bleeding kit and DOT4 brake fluid are required for installation (not included)
• Brake bleeding is required after installation
• Ensure proper caliper and rotor alignment
• Professional installation recommended if unfamiliar with brake systems
